DS-OLBS/BVM/BVS Series

DINGS' offers wide range of Brushless DC Motor electronics for speed and position control.
From low current to Maximum 30A, DINGS' provides 4 different kinds of speed controller via RS485 and Analog command.

Also DINGS' provides CANOpen & EtherCAT based Mini Brushless DC Motor position control and Standard Brushless DC Motor position control solutions.

Mini driver supports Max. 6A Peak current and Standard driver supports Max. 20A Peak current.

Stand Alone DS-BV Series images

DS-BVS-FCAO/FETC

DS-BVS images
  • 1. Input power: DC 12V-48V
  • 2. Output rated current：Continuous current 10A, Max. Current 20A Peak
  • 3. Support BLDC, VCM, PMSM, LSM, DC
  • 4. 6 Inputs and 2 Ouptuts
  • 5. Support CANOpen, EtherCAT protocol
DS-BVS images
Basic Specifications

In a mobile environment, you can move left and right to see the contents (tables).

Adapted Motor DC / BLDC / PMSM / VCM
Current (Torque) Control Control periodic 24KHz
Velocity & Position Control Control periodic 2KHz
Communication Method USB + CANopen or EtherCAT (CoE, FoE)
Auto Tuning Automatic self-configuration and optimization of motor phasing, wires, current loop, velocity control loop.
User Interface GUI : DINGS’ servo studio, Setting, Drive, Motor, Feedback, I/O, Motion
Protective Functions Under-and over-voltage, Over-current, Over-load (with PT), Drive over-temperature, Feedback sensor signal lost
Operating
Environment 		Ambient temperature 0 ~ 45°C
Storage Temperature 0 ~ 70°C
Operating Humidity 10 ~ 90% RH
DS-BVS images
Dimensional Drawing
catalog images
manual Downloads List
File Name Format Size Download
DS-BVS-FETC/FCAO-Hardware Manual PDF 1.17 MB Download
DINGS' Servo Studio Manual PDF 5.35 MB Download
DS-BVS/BVM Series Reference Manual PDF 5.65 MB Download
Software Downloads List
File Name Format Size Download
DINGS' Servo Studio ZIP 4.58 MB Download
DS-BVS-FETC DS-BVM-FETC XML File ZIP 14.27 KB Download
DS-BVS-FCAO DS-BVM-FCAO EDS File ZIP 8.43 KB Download

DS-BVM-FCAO/FETC

DS-BVM images
  • 1. Input power: DC 12V-48V
  • 2. Output rated current：Continuous current 3A, Max. Current 6A Peak
  • 3. Support BLDC, VCM, PMSM, LSM, DC
  • 4. 6 Inputs and 2 Ouptuts
  • 5. Support CANOpen, EtherCAT protocol
DS-BVM images
Basic Specifications

In a mobile environment, you can move left and right to see the contents (tables).

Adapted Motor DC / BLDC / PMSM / VCM
Current (Torque) Control Control periodic 24KHz
Velocity & Position Control Control periodic 2KHz
Communication Method USB + CANopen or EtherCAT (CoE, FoE)
Auto Tuning Automatic self-configuration and optimization of motor phasing, wires, current loop, velocity control loop.
User Interface GUI : DINGS’ servo studio, Setting, Drive, Motor, Feedback, I/O, Motion
Protective Functions Under-and over-voltage, Over-current, Over-load (with PT), Drive over-temperature, Feedback sensor signal lost
Operating
Environment 		Ambient temperature 0 ~ 45°C
Storage Temperature 0 ~ 70°C
Operating Humidity 10 ~ 90% RH
DS-BVM images
Dimensional Drawing
catalog images
manual Downloads List
File Name Format Size Download
DS-BVM-FETC/FCAO Hardware Manual PDF 1.3 MB Download
DINGS' Servo Studio Manual PDF 5.35 MB Download
DS-BVS/BVM Series Reference Manual PDF 5.65 MB Download
Software Downloads List
File Name Format Size Download
DINGS' Servo Studio ZIP 4.58 MB Download
DS-BVS-FETC DS-BVM-FETC XML File ZIP 14.27 KB Download
DS-BVS-FCAO DS-BVM-FCAO EDS File ZIP 8.43 KB Download

DS-OLBS2-FRS4

DS-OLBS2-FRS4 images
  • 1. Isolation of input and output signals
  • 2. External analog and PWM input
  • 3. Start / Stop control & Forward / Reverse control
  • 4. Electrical stop to ensure quick action of motor
  • 5. Rotor protection, Fast response speed and High control accuracy
  • 6. The overload ratio is more than double, and the torque can be achieved the max in low speed
DS-OLBS2-FRS4 images
Basic Specifications

In a mobile environment, you can move left and right to see the contents (tables).

Adapted Motor Less than 80W Brushless DC motor
Power Supply 12 – 24 VDC
Output Current 5 A
Speed Controlled Analog Voltage 0 – 5 V
Structure Wall mounting
Cooling Method Air cooling
Control Signal Full isolation of input and output signals
Protections Over voltage, under voltage, over current, over temperature, abnormal hall signal and other fault alarms
Communication Mode RS-485 Multi-axes communication
Operating
Environment 		Operating Temperature 0 ~ 45°C
Storage Temperature -20 ~ 85°C
Operating Humidity <85% RH
DS-OLBS2-FRS4 images
Dimensional Drawing
catalog images
manual Downloads List
File Name Format Size Download
DS-OLBS2-FRS4 Manual PDF 866.73 KB Download

DS-OLBS4-FRS4

DS-OLBS4-FRS4 images
  • 1. PID speed and current dual loop regulator
  • 2. 20KHz chopper frequency
  • 3. Start / Stop control & Forward / Reverse control
  • 4. Electrical stop to ensure quick action of motor
  • 5. Rotor protection, Fast response speed and High control accuracy
  • 6. The overload ratio is more than double, and the torque can be achieved the max in low speed.
DS-OLBS4-FRS4 images
Basic Specifications

In a mobile environment, you can move left and right to see the contents (tables).

Adapted Motor Less than 200W Brushless DC motor
Power Supply 24 – 48 VDC
Output Current 10 A
Speed Controlled Analog Voltage 0 – 5 V
Structure Wall mounting
Cooling Method Air cooling
Control Signal Full isolation of input and output signals
Protections Over voltage, under voltage, over current, over temperature, abnormal hall signal and other fault alarms
Communication Mode RS-485 Multi-axes communication
Operating
Environment 		Operating Temperature 0 ~ 45°C
Storage Temperature -20 ~ 85°C
Operating Humidity <85% RH
DS-OLBS4-FRS4 images
Dimensional Drawing
catalog images
manual Downloads List
File Name Format Size Download
DS-OLBS4-FRS4 Manual PDF 780.94 KB Download

DS-OLBS6-FSC

DS-OLBS6-FSC images
  • 1. PID speed and current dual loop regulator
  • 2. 20KHz chopper frequency
  • 3. Start / Stop control & Forward / Reverse control
  • 4. Electrical stop to ensure quick action of motor
  • 5. Rotor protection, Fast response speed and High control accuracy
  • 6. The overload ratio is more than double, and the torque can be achieved the max in low speed.
DS-OLBS6-FSC images
Basic Specifications

In a mobile environment, you can move left and right to see the contents (tables).

Adapted Motor Less than 400W Brushless DC motor
Power Supply 24 – 48 VDC
Output Current 15 A
Speed Controlled Analog Voltage 0 – 5 V
Structure Wall mounting
Cooling Method Air cooling
Control Signal Full isolation of input and output signals
Protections Over voltage, under voltage, over current, over temperature, abnormal hall signal and other fault alarms
Communication Mode RS-485 Multi-axes communication
Operating
Environment 		Operating Temperature 0 ~ 45°C
Storage Temperature -20 ~ 85°C
Operating Humidity <85% RH
DS-OLBS6-FSC images
Dimensional Drawing
catalog images
manual Downloads List
File Name Format Size Download
DS-OLBS6-FSC Manual PDF 628.56 KB Download

DS-OLBS8-FRS4

DS-OLBS8-FRS4 images
  • 1. Hall sensor or sensorless control mode can be set and both modes are compatible.
  • 2. External analog input and PWM (1~2KHz) input
  • 3. Start / Stop control & Forward / Reverse control
  • 4. Electrical stop to ensure quick action of motor
  • 5. Rotor protection, Fast response speed and High control accuracy
  • 6. Load without deceleration, power compensation, large starting torque
  • 7. The overload ratio is more than double, and the torque can be achieved the max in low speed
DS-OLBS8-FRS4 images
Basic Specifications

In a mobile environment, you can move left and right to see the contents (tables).

Adapted Motor Less than 750W Brushless DC motor
Power Supply 24 – 48 VDC
Output Current 30 A
Speed Controlled Analog Voltage 0 – 5 V
Structure Wall mounting
Cooling Method Air cooling
Control Signal Full isolation of input and output signals
Protections Over voltage, under voltage, over current, over temperature, abnormal hall signal and other fault alarms
Communication Mode RS-485 Multi-axes communication
Operating
Environment 		Operating Temperature 0 ~ 45°C
Storage Temperature -20 ~ 85°C
Operating Humidity <85% RH
DS-OLBS8-FRS4 images
Dimensional Drawing
catalog images
manual Downloads List
File Name Format Size Download
DS-OLBS8-FRS4 Manual PDF 854.39 KB Download
